SwapLoader SL-220 22k Hooklift Frame
Item No.
51H95– Fixed Jib
52H51– Adjustable Jib | |
LIFT / DUMP CAPACITY
(INCLUDING CONTAINER) | 22,000 lb. |
| DUMP ANGLE | 53° |
| HOIST WEIGHT* | Fixed: 4,080 lb. or Adjustable: 4,270 lb. |
| HOOK TO REAR ROLLER | 193.81″ |
| HOOK HEIGHT | Fixed: 53.88″ or Adjustable: 53.88″ or 61.75″ |
| HOIST HEIGHT | 9″ |
| HOIST CG | 97.8″ |
| OPTIMUM BODY LENGTHS | 18′ – 20′ |
| POTENTIAL BODY LENGTHS* | 14′ – 22′ |
| BODY LONGSILL WIDTH* | 41.63″ / 40.50″ |
| HYDRAULIC PUMP TYPE | Gear (4.46) |
| FLOW @ PUMP RPM* | 17.4 GPM @ 1,000 RPM |
| RELIEF PRESSURE | 2,800 PSI |
| HYDRAULIC RESERVOIR | 25 gallons |
| GVW RANGE* | 25,000 lb. – 35,000 lb. |
| CAB-AXLE DIMENSIONS* (Single Axle) | 156″ – 174″ |
| CAB-TRUNNION DIMENSIONS* (Tandem Axle) | 148″ – 160″ |
| CLEAR FRAME RAIL* | 220″ |
| FRAME HEIGHT | up to 43″ |
*Accessories not included
PTO options for most vehicles
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
SwapLoader SL-75 7.5k Hooklift Frame
Item No.
SL-75-EHV– EHV Fixed Jib
SL-75-PWR– Power Fixed Jib | |
LIFT / DUMP CAPACITY
(INCLUDING CONTAINER) | 7,500 lb. |
| DUMP ANGLE | 56° |
| HOIST WEIGHT* | Fixed: 1,290 lb. |
| HOOK TO REAR ROLLER | 114.38″ |
| HOOK HEIGHT | Fixed: 35 5/8″ |
| HOIST HEIGHT | 5.25″ |
| HOIST CG | 59.7″ |
| OPTIMUM BODY LENGTHS | 10′ – 12′ |
| POTENTIAL BODY LENGTHS* | 9′ – 13′ |
| BODY LONGSILL WIDTH* | 41.63″ / 39.00″ |
| HYDRAULIC PUMP TYPE | Gear (0.85) |
| FLOW @ PUMP RPM* | 3.1 GPM @ 1,000 RPM |
| RELIEF PRESSURE | 3,250 PSI |
| HYDRAULIC RESERVOIR | 7 gallons |
| GVW RANGE* | 14,000 lb. – 16,000 lb. |
| CAB-AXLE DIMENSIONS* | 84″ – 96″ |
| CLEAR FRAME RAIL* | 126″ |
| FRAME HEIGHT | up to 38″ |
*Accessories not included
PTO options for most vehicles
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
SwapLoader SL-220 22k Hooklift Frame
Item No.
42H21– Fixed Jib
43H37– Adjustable Jib | |
LIFT / DUMP CAPACITY
(INCLUDING CONTAINER) | 33,000 lb. |
| DUMP ANGLE | 58° |
| HOIST WEIGHT* | Fixed: 5,090 lb. or Adjustable: 5,250 lb. |
| HOOK TO REAR ROLLER | 167.50″ |
| HOOK HEIGHT | Fixed: 61.75″ or Adjustable: 53.88″ or 61.75″ |
| HOIST HEIGHT | 11″ |
| HOIST CG | 88.8″ |
| OPTIMUM BODY LENGTHS | 14′ – 16′ |
| POTENTIAL BODY LENGTHS* | 12′ – 18′ |
| BODY LONGSILL WIDTH* | 40.50″ / 41.63″ |
| HYDRAULIC PUMP TYPE | Gear (3.83) |
| FLOW @ PUMP RPM* | 22.3GPM @ 1,500 RPM |
| RELIEF PRESSURE | 3,500 PSI |
| HYDRAULIC RESERVOIR | 30 gallons |
| GVW RANGE* | 33,000 lb. or Greater |
| CAB-AXLE DIMENSIONS* (Single Axle) | 142″ – 156″ |
| CAB-TRUNNION DIMENSIONS* (Tandem Axle) | 124″ – 136″ |
| CLEAR FRAME RAIL* | 195″ |
| FRAME HEIGHT | up to 43″ |
*Accessories not included
PTO options for most vehicles
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
Swaploader SL-112 12k Hooklift Frame
Item No.
14H12 – Adjustable Jib | |
LIFT / DUMP CAPACITY
(INCLUDING CONTAINER) – | 12,000 lb. |
| DUMP ANGLE | 55° |
| HOIST WEIGHT* | Adjustable: 2,060 lb. |
| HOOK TO REAR ROLLER | 135.38″ |
| HOOK HEIGHT | Adjustable: 35 5/8″ or 53 7/8″ |
| HOIST HEIGHT | 6.625″ |
| HOIST CG | 68.8″ |
| OPTIMUM BODY LENGTHS | 12′ – 14′ |
| POTENTIAL BODY LENGTHS* | 10′ – 15′ |
| BODY LONGSILL WIDTH* | 41.63″ / 40.50″ |
| FLOW (Recommended) | 7.2 GPM |
| RELIEF PRESSURE | 3,250 PSI |
| HYDRAULIC RESERVOIR | 15 gallons |
| GVWR RANGE* | 16,000 lb. – 23,000 lb. |
| CAB-AXLE DIMENSIONS* | 108″ – 120″ |
| CLEAR FRAME RAIL* | 152″ |
| FRAME HEIGHT | up to 38″ |
*Accessories not included
PTO options for most vehicles
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
2016 Genie Z-40/23N Electric Boom Man Lift
2016 Genie Z-40/23N
Powered by 48V Electric System
Hour meter reads: 761 hours
4×2
40’5” Platform Height / 46’5” Working Height
22’8” Horizontal Reach
21’3” Up and Over Clearance
5’ Jib
3’10” Man Basket
Basket Rated Weight: 500lbs
Rated Gradeability: 30%
Power to the Platform
Operating Weight: 15,250lbs
Foam-Filled Tires
Good tires all around!
2016 Genie Z-45/25 4×4 Boom Man Lift
2016 Genie Z-45/25
Deutz Diesel Engine
Hour meter reads: 1,469 hours
4×4
45’5” Platform Height / 51’6” Working Height
25’1” Horizontal Reach
23’1” Up and Over Clearance
6’ Man Basket
Basket Rated Weight: 500lbs
Rated Gradeability: 45%
Onboard Generator (Power to the Platform)
Operating Weight: 14,298lbs
315/55D20 Foam-Filled Tires
Good tires all around!
Unit was Greased and Serviced!
2026 Duramag Aluminum Rack body
- Custom Lengths available 7′-24′
- Customizable options
- All Aluminum (6000 Series) Box Tube Construction
- Heavy 2” x 3” Long Sills (6000 Series)
- 24” OC Cross Members 2” x 3” (6000 Series)
- Premium G-tube Perimeter Frame (6000 Series)
- Extruded Aluminum Flooring – (Tongue and Groove – 6000 Series)
- Extruded Aluminum Headboard with Glide Track for Easy On/Off Accessories
- LED Lights Fully Pre-Wired Inside Box Tube
- Stake Pockets & Rub Rail (Both Side & Rear)
- Square Headboard with Expanded Metal Window
- Anti-Rattle HDPE Shims with Stainless Rivets on all Stakes
- HDPE Body Blocks that Protect Against Rack Abrasion
- HD Version includes 1″ x 1″ Perimeter Tube Frame around all Rack Sections
- All Aluminium Rack Sections with Stainless Steel Locking Spring Pin
- Proprietary Spring-loaded Release Lever
- Anti-Rattle Rubber Bumpers
- Available on anybody where stake body sides apply
2026 PJ ALUMINUM DELUXE SKIRTED FLATBED ALGB-02845842 LONG BED
- Available Lengths – 84”, 8’6”, 9’4”, 11’4”
- Headache Rack – Aluminum Tube
- Lighting – 6” Glow Oval LED
- Deck – Extruded Aluminum
- Frame Rails – 4” Structural Channel Steel
- Crossmembers – 3” Aluminum Extruded Channel
- Rear Skirt– Solid one piece with tapered corners for turning radius with recessed steps
- GN Hitch – 30k lbs. B&W gooseneck hitch with welded ball
- Rear Receiver – 24k lbs. B&W 2.5” receiver
- Fuel Fill – Angled
- 12v Trailer Plug – Round 7 pin RV style in GN well, 7 pin / 4 way combo on rear
- Light Box – Aluminum
- Marker Lighting – Bullet LED
- Toolbox – 4 Lockable Flush-Mounted Toolboxes with large front utility toolboxes
- Toolbox handles – Black T-handle Compression
- Fenders – Aluminum
- Rear Lighting – 6” Oval LED
- Side Steps – Front and rear behind Fenders
- Side Rails – 3/8”x2” Aluminum Extrusion with Aluminum Stake pockets
Not sure which truck bed is right for you? Give us a call at 603.417.2112
Installation available!
2026 Duramag Aluminum Flatbed TB081104-AL Truck Body 8′ SRW
- All Extruded 6005 T6 Alum Box Tube Construction
- Long Sills to Compensate for Hump in Truck Frame
- G-Tube Perimeter Frame
- Extruded Aluminum Headboard w/Accessory Track
- OEM Plug & Play Wire Harness – Body End
- Cast Aluminum Fuel Fill Dish – Streetside Fronts
- 12″ Diamond Plate Apron
- 2×3.188 Long Sills
- 1.5″ x 3.125 Cross Members, 16″ OC
- T&G Extruded Alum Flooring
- All Pre-Wired w/LED Lights Inside Box Tube
- Stake Pockets & Rub Rail
- Lighted Headboard
*SUBFRAME SOLD SEPARATELY
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
2016 Genie GS-2632 Electric Scissor Lift
2016 Genie GS-2632
Electric Powered (24v)
Hour Meter reads: 371.5
Platform Height: 26’1”
Working Height: 32’ 1”
Platform Rated Capacity: 500lbs
Machine Weight: 4,500lbs
Solid Non-Marking Wheels
Slide out Deck extension
Onboard Charger
Power to Platform
Dimensions: 8’x2’ 6”x 7’ 4” (With rails up) (6’4” with rails down)
Operates as it should
