DOWNEASTER 9′ STEEL DUMP BODY DED09396

• 10 gauge construction throughout
• Dirt shedding , sloped design at side plate and tailgate top
• Double panel side plates equal over 1/4″ thickness.
• Full depth 3/16″rear corner pillars incorporate recessed lighting, keyhole banjo eyes and lower tailgate pin receiver.
• All lighting is LED rubber mounted and NTEA and Federal compliant.
• 2 1/2″ shorter deck height (9′ only)
• Mounting height of 9.5″ chassis to floor (9′ only)
• 10″ board extension pockets ease of install & future optional / custom overhang.
• Self aligning rear latch release for the top gate pins
• Integrated tarp hooks
• DuPont™ Imron® Elite black oven cured paint w/ epoxy primer

FLOOR & UNDERSTRUCTURE

• 4″ x 5.7# Channel long sills and 3″ channel cross members (9′)
• 6″ x 8.2# Channel long sills (10′, 10.5′ 11′)
• 3/16″ Stainless formed 7″ long sills (SS body)
• 3″ stainless tubing, interlaced cross members (SS body)
• Two piece 10 gauge floor with 45 degree slopped corners where meets seamless side plate.
• Greasable Bronze bearings for underbody release mechanisms

TAILGATE

• Formed 10 gauge inner, outer and end panels.
• 1″ hardened pins, (1″ Stainless) with plasma cut latch receiving lock fingers
• Adjustable 1/4″ chain for spreading aggregate material & holding gate in down position

Installation is available!

Not sure which truck bed is right for you? Give us a call at 603.417.2112

2025 DURAMAG S-SERIES ALUMINUM UTILITY BED LONG BED

• Standard Features
• All Aluminum Extruded Box Tube Construction
• Fully Welded Construction – No Bolts to Come Loose
• Extreme Duty .625″ Interlocking Extruded Flooring
• Heavy Slam Latch Tailgate
• Inner Bed Walls & Top of Compartments 3/16″ Smooth Sheet
• One Piece Sides
• Welded Fender Flares – Superior Strength & Rigidity
• Tread Plate Splash Guards on Front
• 40″ Compartment Height
• Radius Corner Traditional Swing Doors
• Blind Compression T-Handles
• Heavy Duty Hidden Hinges
• Adjustable Shelf Brackets in All Compartments (One Shelf Included in Each Compartment)
• Pass Through Panel Between Rear & Center Compartments
• LED Marker Lights, Installed
• LED Penny Lights for Compartments, Installed
• Ultra-Thin 5.5″ LED STT/BU Body Lights, Installed
• OEM Plug & Play Wire Harness, Body End Only (Adaptors Sold Separately)
• Powder Coated White, Black or Red
• Upfit Hardware Kit, Shipped Loose
• (1) Cast Aluminum Fuel Fill Dish, Installed (Street-side Front on Pickups / Street-side Rear on Cab Chassis)

Includes subframe and rear bumper. Additional options and features available.

Installation is available!

Not sure which truck bed is right for you? Give us a call at 603.417.2112
