2024 Haulotte/Bil-Jax 55XA 4×4 Hybrid Self Propelled Man Lift
Powered By: Bi-Energy (Kohler Gas Engine – 26Hp & 24v DC Electric Battery Motor ) (4x 6V Batteries 260 Amp-Hr Batteries)
55′3″ Platform Height / 61′3″ Work Height / 33’5″ Horizontal Reach
Up and Over Height: 23’ 1”
Hydraulic Jib Length: 4’3” w/ 150° Vertical Motion
Lift Capacity: 500lbs
4×4
Four wheel Steer_
Gradeability: 45%
Hydraulic Outriggers/Stabilizers
-Self Leveling System and Self Leveling Platform
Electric Power, Air and Water to the Platform
Inboard 25 Amp Charger
Onboard 4,000W Generator (for charging battery system)
Integrated Forklift Pockets
Working Width: (LxW) 13’ 11” x12’9”
Turntable Rotation: 350° non-continuous
Basket Width: 5’
Minimum Weight: 6,000lbs
Overall Dimensions: (LxWxH) 21’2″x5’8″x6′9″
*18 Month Factory Warranty (Parts & Labor) & 5yr Structural Warranty
SEE ATTACHED SPEC SHEET IN PHOTOS!
AUTHORIZED HAULOTTE DEALER IN PARTS, SERVICE AND SALES!
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?!
WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2024 Haulotte/Bil-Jax 5533A Towable Man Lift
Powered by: 24v DC Electric Motor w/ 4x 6V 245 Amp-Hr Batteries
55′3″ Platform Height / 61′3″ Work Height / 33’5″ Horizontal Reach
Up and Over Height: 23’ 1”
Hydraulic Jib Length: 4’3” w/ 150° Vertical Motion
Lift Capacity: 500lbs
Hydraulic Outriggers/Stabilizers
-Self Leveling System and Self Leveling Platform
Electric Power, Air and Water to the Platform
Inboard 25 Amp Charger
Integrated Forklift Pockets
Hydraulic Surge Brakes (Trailer)
Working Width: (LxW) 14’8” x15’
Turntable Rotation: 350° non-continuous
Basket Width: 4’1”
Minimum Weight: 4.800lbs
Overall Dimensions: (LxWxH) 23’8″ x 5’7″ x 6′9″
*18 Month Factory Warranty (Parts & Labor) & 5yr Structural Warranty
SEE ATTACHED SPEC SHEET IN PHOTOS!
Ask About Optional Upgrades:
- A) Platform Rotator – $2,050
- B) Drive & Set (2WD Assist/Traction-Drive) – $6,050
- C) Spare Tire & Mounting Kit – $725
- D) Honda Gas Generator – $4,050
AUTHORIZED HAULOTTE DEALER IN PARTS, SERVICE AND SALES!
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?!
WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2024 Haulotte/Bil-Jax 6543A Towable Man Lift
Powered by: 24v DC Electric Motor w/ 4x 6V 245 Amp-Hr Batteries
65′ Platform Height / 71′ Work Height / 43’ Horizontal Reach
Up and Over Height: 24’ 2”
Hydraulic Jib Length: 4’3” w/ 170° Vertical Motion
Lift Capacity: 500lbs
Hydraulic Outriggers/Stabilizers
-Self Leveling System and Self Leveling Platform
Electric Power, Air and Water to the Platform
Inboard 25 Amp Charger
Integrated Forklift Pockets
Hydraulic Surge Brakes (Trailer)
Working Width: (LxW) 14’8” x15’
Turntable Rotation: 350° non-continuous
Basket Width: 4’1”
Minimum Weight: 7.700lbs
Overall Dimensions: (LxWxH) 24’ x 5’11″ x 7′
*18 Month Factory Warranty (Parts & Labor) & 5yr Structural Warranty
SEE ATTACHED SPEC SHEET IN PHOTOS!
Ask About Optional Upgrades:
- A) Platform Rotator – $2,050
- C) Spare Tire & Mounting Kit – $725
- D) Honda Gas Generator – $4,050
AUTHORIZED HAULOTTE DEALER IN PARTS, SERVICE AND SALES!
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?!
WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2024 Haulotte/Bil-Jax 45XA 4×4 Hybrid Self Propelled Man Lift
Powered By: Bi-Energy (Kohler Gas Engine – 26Hp & 24v DC Electric Battery Motor ) (4x 6V Batteries 260 Amp-Hr Batteries)
45′ Platform Height / 51′ Work Height / 27’ Horizontal Reach
Up and Over Height: 20’ 9”
Hydraulic Jib Length: 4’3” w/ 150° Vertical Motion
Lift Capacity: 500lbs
4×4
Gradeability: 45%
Hydraulic Outriggers/Stabilizers
-Self Leveling System and Self Leving Platform
Electric Power, Air and Water to the Platform
Inboard 25 Amp Charger
Onboard 4,000W Generator (for charging battery system)
Integrated Forklift Pockets
Working Width: (LxW) 12’ 4” x11’4”
Turntable Rotation: 350° non-continuous
Basket Width: 5’
Minimum Weight: 5,400lbs
Overall Dimensions: (LxWxH) 18’2″x5’6″x6′7″
*18 Month Factory Warranty (Parts & Labor) & 5yr Structural Warranty
SEE ATTACHED SPEC SHEET IN PHOTOS!
AUTHORIZED HAULOTTE DEALER IN PARTS, SERVICE AND SALES!
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?!
WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2024 Haulotte/Bil-Jax 4527A Towable Man Lift
Powered by: 24v DC Electric Motor w/ 4x 6V 245 Amp-Hr Batteries
45′ Platform Height / 51′ Work Height / 27’ Horizontal Reach
Up and Over Height: 20’ 9”
Hydraulic Jib Length: 4’3” w/ 150° Vertical Motion
Lift Capacity: 500lbs
Hydraulic Outriggers/Stabilizers
-Self Leveling System and Self Leving Platform
Electric Power, Air and Water to the Platform
Inboard 25 Amp Charger
Integrated Forklift Pockets
Hydraulic Surge Brakes (Trailer)
Working Width: (LxW) 13’ 9” x13’6”
Turntable Rotation: 350° non-continuous
Basket Width: 4’1”
Minimum Weight: 3.960lbs
Overall Dimensions: (LxWxH) 20’8″x5’6″x6′8″
*18 Month Factory Warranty (Parts & Labor) & 5yr Structural Warranty
SEE ATTACHED SPEC SHEET IN PHOTOS!
Ask About Optional Upgrades:
- A) Platform Rotator – $2,050
- B) Drive & Set (2WD Assist/Traction-Drive) – $6,050
- C) Spare Tire & Mounting Kit – $725
- D) Honda Gas Generator – $4,050
AUTHORIZED HAULOTTE DEALER IN PARTS, SERVICE AND SALES!
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?!
WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2024 Haulotte/Bil-Jax 3632T Towable Man Lift
Powered by: 24v DC Electric Motor w/ 4x 6V 245 Amp-Hr Batteries
36′ Platform Height / 43′6” Work Height / 32’ Horizontal Reach
Lift Capacity: 500lbs
Hydraulic Outriggers/Stabilizers
-Self Leveling System and Self Leveling Platform
Electric Power, Air and Water to the Platform
Onboard 25 Amp Charger
Integrated Forklift Pockets
Hydraulic Surge Brakes (Trailer)
Working Width: (LxW) 13’ 9” x13’6”
Turntable Rotation: 350° non-continuous
Basket Width: 4’1”
Minimum Weight: 4,400lbs
Overall Dimensions: (LxWxH) 22’8″x5’6″x6′8″
*2yr Factory Warranty (Parts & Labor) & 5yr Structural Warranty
SEE ATTACHED SPEC SHEET IN PHOTOS!
Ask About Optional Upgrades:
- A) Platform Rotator – $2,050
- B) Drive & Set (2WD Assist/Traction-Drive) – $6,050
- C) Spare Tire & Mounting Kit – $725
- D) Honda Gas Generator – $4,050
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?!
WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2016 Haulotte 3947E Compact Electric Scissor lift
2016 Haulotte 3947E
Electric Powered
Hour Meter Reads: 348 Hours
Platform Height: 38’9”
Working Height: 44’9”
Platform Rated Capacity: 770lbs
Machine Weight: 7,236lbs
Gradeability: 23%
Wheelbase: 73”
Solid Non-Marking Wheels
36” Slide out Deck extension
Onboard DC Charger
Power to Platform
Drivable at Full Height
Dimensions: 8’2”x4’x8’3”
Operates as it should
2018 NIFTYLIFT SD50DE Hybrid 4×4 Boom Man Lift
Bi-Energy (Kubota Diesel & DC Electric Battery)
Hour Meter Reads: 743 Hours
49′ 6” Platform Height / 56’ Work Height / 28’ 6” Horizontal Reach
Hydraulic Outriggers/Stabilizers
4×4
Electric Power to the Platform
Working Width: 14’ 5”
Basket Width: 3’ 7”
Minimum Weight: 5,950lbs
Overall Dimensions: (LxWxH) 18’4″x5’3″x7′3″
SEE ATTACHED SPEC SHEET IN PHOTOS!
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?! WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
2019 Niftylift TM34MG Towable Man Lift
2019 Niftylift TM34MG
Powered by: Honda Gas Engine
34′ Platform Height / 40′ 6” Work Height / 16’6” Horizontal Reach
Manual Outriggers/Stabilizers
Width: 4’ 11”
Retractable Axle width: 3’7”
Working Width: 8’10”
Basket Width: 3’ 7”
Minimum Weight: 2,560lbs
2″ Receiver Hitch
Ready to Work!
30 Day Parts/Labor Warranty!
$15,900
2024 NIFTYLIFT SD50DE Hybrid 4×4 BOOM MAN LIFT
Bi-Energy (Kubota Diesel & DC Electric Battery)
49′ 6” Platform Height / 56’ Work Height / 28’ 6” Horizontal Reach
Hydraulic Outriggers/Stabilizers
4×4
Electric Power to the Platform
Working Width: 14’ 5”
Basket Width: 3’ 7”
Minimum Weight: 5,950lbs
Overall Dimensions: (LxWxH) 18’4″x5’3″x7′3″
*1yr Factory Warranty (Parts & Labor) & 5yr Structural Warranty — Optional 2yr, 3yr & 4yr Warranties Available*
SEE ATTACHED SPEC SHEET IN PHOTOS!
Optional Upgrades:
- A) WATER Line to Platform
- B) AIR Line to Platform
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?! WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION!
