2016 Ram 4500 Altec Utility Bucket Truck
Powered by: Kubota Diesel
33′ 6” Platform Height / 40′ Work Height / 20’ Horizontal Reach
Hydraulic Outriggers/Stabilizers
Electric Power to the Platform
Gradeability: 60%
Travel speed: 1mph
Standard Width: 3’9”
Retracted Width: 2’7”
Working Width: 9’10”
Basket Width: 3’7”
Basket Rated Capacity: 500lbs
Minimum Weight: 3,990lbs
Overall Dimensions: (LxWxH) 13’1”x3’9″x6’5″
*1yr Factory Warranty (Parts & Labor) & 5yr Structural Warranty — Optional 2yr, 3yr & 4yr Warranties Available*
SEE ATTACHED SPEC SHEET IN PHOTOS!
Optional Upgrades:
A) Non-Marking White Tracks
B) Air to Platform
C) Water to Platform
NOT THE MODEL/CONFIGURATION YOU ARE LOOKING FOR?! WE CAN ORDER ANY MODEL YOU’D LIKE INQUIRE FOR MORE INFORMATION !
DownEaster 11′ Steel Dump Body DED11396
10 gauge construction throughout
Dirt shedding , sloped design at side plate and tailgate top
Double panel side plates equal over 1/4″ thickness.
Full depth 3/16″rear corner pillars incorporate recessed lighting, keyhole banjo eyes and lower tailgate pin receiver.
All lighting is LED rubber mounted and NTEA and Federal compliant.
2 1/2″ shorter deck height (9′ only)
Mounting height of 9.5″ chassis to floor (9′ only)
10″ board extension pockets ease of install & future optional / custom overhang.
Self aligning rear latch release for the top gate pins
Integrated tarp hooks
DuPont™ Imron® Elite black oven cured paint w/ epoxy primer
FLOOR & UNDERSTRUCTURE
4″ x 5.7# Channel long sills and 3″ channel cross members (9′)
6″ x 8.2# Channel long sills (10′, 10.5′ 11′)
3/16″ Stainless formed 7″ long sills (SS body)
3″ stainless tubing, interlaced cross members (SS body)
Two piece 10 gauge floor with 45 degree slopped corners where meets seamless side plate.
Greasable Bronze bearings for underbody release mechanisms
TAILGATE
Formed 10 gauge inner, outer and end panels.
1″ hardened pins, (1″ Stainless) with plasma cut latch receiving lock fingers
Adjustable 1/4″ chain for spreading aggregate material & holding gate in down position
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
DownEaster 12′ Landscape Dump Body DELD1296
5″ x 6.7# Channel long sills
3″ x 4.1# Channel cross members
10GA floor, 2 pc
12GA side plates & bulkhead
52″ Curb side door, standard
Structural tubing corner posts
3/16″ thick rear cross member/apron with
tail and reverse light knockouts
3/8″ D rings at each inside corner
All lighting is LED rubber mounted and NTEA and Federal
compliant.
Class 20 & 40 (single cylinder) hoists available
Mounted & painted Sub frame for ease of installation
Mounting hardware and brackets provided
Epoxy primer with Phosphate prewash
Imron® Elite black oven
cured paint w/ epoxy primer
Cab Shield
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
SwapHogg 12′ Roll-off Frame SH1512EW-G2
Low profile sub frame and mounting height
6″ bore x 15″ stroke hoist, standard.
50 deg. Dump angle (10 ton) (13″ high side w/ drive on gate)
6″ x 2″ structural tube frame.
Auto locking body latch w/ ergonomic pull handle.
Warn 15K electric industrial winch w/ tensioner
303 Stainless side rollers pressed over greaseless bronze bearings
303 Stainless rear rollers pressed over DOM steel
with greaseless/replaceable stainless shafts
Stainless steel side guide rails
Exterior mounted body prop
Stainless Steel pump cover
Spacer plates between upper & lower frames minimizes rust contact points
“Winch-in” stop switch
Able to accept other body brands
30′ EIPS 1/2″ cable w/ 4.5 ton swivel hook
Nylon cable roller, self lubricating, for less cable wear
4 button, in cab, control pendant
1/0 GA battery cables w/ 600 amp fuse
PPG cured paint w/ corrosion resistant epoxy primer
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
SwapHogg 11′ Dump Body with 13″ Drop Sides DESH1196 DBD3
Available in 9′ and 11′
10 GA flooring
10 GA side plates
3-5 yard
13″ high drop sides
4 D-rings
24″ high drive on tailgate w/ latch
38″ bulkhead
Front handle release lower latch
Steel rear rollers
Stainless steel tailgate latch
PPG cured paint w/ corrosion
resistant epoxy primer
Standard Features
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
SwapHogg 12′ Container Body DESH1250 SDT-S
Available in 10′ (11.5 yard) and 12′ (13 yard)
Single door
3″ Structural channel
cross members spaced 16″ on center
Floor constructed with 10 GA steel
Front, side, & gate panels
constructed with 12 GA steel
Doors constructed with 3″x 3″ tubing
Rear posts constructed with 3/16″ steel
Front & side top rails constructed with
3″x 3″ tubing
PPG cured paint w/ corrosion resistant epoxy primer
Steel ground rollers
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
DownEaster 11′ Stainless Dump Body DEDS11396
10 gauge construction throughout
Dirt shedding , sloped design at side plate and tailgate top
Double panel side plates equal over 1/4″ thickness.
Full depth 3/16″rear corner pillars incorporate recessed lighting, keyhole banjo eyes and lower tailgate pin receiver.
All lighting is LED rubber mounted and NTEA and Federal compliant.
2 1/2″ shorter deck height (9′ only)
Mounting height of 9.5″ chassis to floor (9′ only)
10″ board extension pockets ease of install & future optional / custom overhang.
Self aligning rear latch release for the top gate pins
Integrated tarp hooks
DuPont™ Imron® Elite black oven cured paint w/ epoxy primer
FLOOR & UNDERSTRUCTURE
4″ x 5.7# Channel long sills and 3″ channel cross members (9′)
6″ x 8.2# Channel long sills (10′, 10.5′ 11′)
3/16″ Stainless formed 7″ long sills (SS body)
3″ stainless tubing, interlaced cross members (SS body)
Two piece 10 gauge floor with 45 degree slopped corners where meets seamless side plate.
Greasable Bronze bearings for underbody release mechanisms
TAILGATE
Formed 10 gauge inner, outer and end panels.
1″ hardened pins, (1″ Stainless) with plasma cut latch receiving lock fingers
Adjustable 1/4″ chain for spreading aggregate material & holding gate in down position
Installation is available!
Not sure which truck bed is right for you? Give us a call at 603.417.2112
